Newest 20 Plate Wort Chiller Draft Beer Homebrew Chiller Stainless Stee 304 Heat Exchanger
Plate chillers work by running cold water through every-other plate, and running wort through the plates in between. This maximizes the surface area for the fastest cooling possible, getting your wort to a safe fermenting temperature much faster than immersion chillers ever could.
· Material :304 Stainless with 99.9% Copper Brazing
· Offering superior heat exchange performance in a simple effective design.
· Plate chillers can be operated with a gravity system or with a pump.
· The wort chilling rate is depending on tap water temperature and rate of flow, colder of water, more slowly of wort flow, chilling is faster
Items : 20 Plates Wort chiller
Material : Stainless steel & Copper
Function : Beer Cooling
Heat Transfer Area/plate: 0.012m2(0.14ft2)Thickness of plates: 0.3 mm(0.0118")Max Flow Rate: 66.6L/min(17.6gpm)Design Pressure:1.0 Mpa(145 psi)Test Pressure: 2.0 Mpa(290 psi)Refrigeration Capacity: 1-5 KW(3400-17000 BTU/hour)Package Includes:
1 x 20 plate Wort Chiller
